Solar collector-air heater with heat accumulator
- Authors: Alkhasov A.B.1, Dibirov Y.A.1, Badavov G.B.1
-
Affiliations:
- Institute of Geothermy and Renewable Energy Problems — branch of the United Institute of High Temperatures of the Russian Academy of Sciences
- Issue: No 5 (2025)
- Pages: 47-60
- Section: Articles
- URL: https://journal-vniispk.ru/0002-3310/article/view/320982
- DOI: https://doi.org/10.7868/S3034649525050035
- EDN: https://elibrary.ru/maksia
- ID: 320982
Cite item
Abstract
The use of heat accumulators charged by solar energy allows to significantly improve the operation of solar air heaters, which is explained by the ability of such systems to function effectively without a fuel backup even in the complete absence of direct solar radiation. The main disadvantage of existing designs of solar air heaters with heat accumulators is the incomplete use of the surface of the container with heat-accumulating material in the charge and discharge cycles. A new design solution for a solar collector-air heater is proposed, which ensures the use of the entire external surface of the tubular containers with heat-accumulating material in the process of heat exchange during the operation of the installation. The laboratory and full-scale tests of an experimental sample of such an installation have obtained data on the heat of fusion of the heat-accumulating composition and the productivity of heated air in different periods of the year. The implementation of such a plant in the climatic conditions of Makhachkala allows for the production of heated air in a volume of up to 734 m3/day from each square meter of absorber and up to 21 m3/day from 1 kg of the adopted heat-accumulating composition.
About the authors
A. B. Alkhasov
Institute of Geothermy and Renewable Energy Problems — branch of the United Institute of High Temperatures of the Russian Academy of Sciences
Author for correspondence.
Email: alibek_alhasov@mail.ru
Makhachkala, Russia
Y. A. Dibirov
Institute of Geothermy and Renewable Energy Problems — branch of the United Institute of High Temperatures of the Russian Academy of Sciences
Email: jakhya@yandex.ru
Makhachkala, Russia
G. B. Badavov
Institute of Geothermy and Renewable Energy Problems — branch of the United Institute of High Temperatures of the Russian Academy of Sciences
Email: lotos155@yandex.ru
Makhachkala, Russia
References
- Бутузов В.А.,Шетов В.Х., Брянцева Е.В., Бутузов В.В., Гнатюк И.С.Солнечные коллекторы. Тенденции совершенствования конструкций // Альтернативная энергетика и экология, 2009. № 10(78). С.41–51.
- Велижанин А.А., Мингалеева Р.Д., Бессель В.В., Серовайский А.Ю.Изучение устройства и принципа действия солнечного коллектора: Учебно-методическое пособие / М.: Издательский центр РГУ нефти и газа (НИУ) имени И.М. Губкина, 2023. 74 с.
- Королева Д.А., Шайдаков В.В., Целищев В.А.Солнечная энергетика М.: Инфра-Инженерия, 2023. 140 с.
- Алхасов А.Б. Возобновляемая энергетика.М.: Физматлит, 2010. 256 с.
- Romdhane B.S.The air solar collectors: Comparative study, Introduction of baffles to favor the heat transfer // Sol Energy. 2007. No. 81(1). P.139–149.
- Akpinar E.K., Koçyigit F.Experimental investigation of thermal performance of solar air heater having different obstacles on absorber plates // Int. Commun Heat Mass. 2010. No. 37(4). P. 416–421.
- Omojaro A.P., Aldabbagh L.B.Y. Experimental performance of single and double pass solar air heater with fins and steel wire mesh as absorber // Appl. Energ. 2010. No. 87(12). P. 3759–3765.
- Пат.РФ№ 2252374МПКF 24J 2/04,F 24J 2/24.Солнечныйаккумулятортепла /Мартынов В.И.,Скоробатюк В.В.,Чуверин И.И.,Шаров Л.А.Опубл. 20.05.2005 //Б.И. 2005. № 14.
- Пат.РФ№ 2258874МПКF 24J 2/24, F 24J 2/26, F 24J 2/34.Солнечныйколлектор /Страшко В.В.,Подлепич В.Ю.,Безнощенко Д.В.Опубл. 20.08.2005 //Б.И. 2005. № 23.
- Пат.РФ№ 2234034МПКF 24J 3/02, E 03G 7/02, F 03 D 9/00.Солнечная ветроустановка /Бабаев Б.Д.Опубл.10.08.2004 //Б.И. 2005. № 22.
- Пат.РФ№ 2680639МПКF 24S 10/55, F 24S 60/10.Солнечныйвоздухонагреватель /Дибиров Я.А.,Алхасов А.Б.,Дибиров М.Г.,Дибиров К.Я.,Дибирова М.М.,Ильясов А.М.Опубл.22.02.2019 //Б.И. 2019. № 6.
- Лариков Н.Н.Теплотехника. Учеб. для вузов / М.: Стройиздат, 1985. 432 с.
- АВОК Справочное пособие 1-2004. Влажный воздух.URL: http://www.znaytovar.ru/gost/2/AVOKSpravochnoe_posobie12004.html.pdf
- Малявина Е.Г. Теплопотери здания: справочное пособие / М.: АВОК-ПРЕСС, 2007. 144 с.
- Осмонов О.М. Расчет биоэнергетической установки: Методические указания / М.: Изд-во ФГБНУ “Росинформагротех”, 2017. 68 с.
- СП 41-103-2000. Проектирование тепловой изоляции оборудования и трубопроводов. ГосстройРоссии /М.:ГУПЦПП, 2001.
- Sharma A., Tyagi V., Chen C., Buddhi D.Review on thermal energy storage with phase change materials and applications // Renewable and Sustainable Energy Reviews. 2009. No. 13. P. 318–345.
