Email this article CALCULATION OF THE INFLUENCE OF ADHESIVE PROPERTIES OF THE COUPLANT ON THE ACOUSTIC FIELD
- Authors: Michurov A.V.1, Sokolkin A.V.2
-
Affiliations:
- OOO Al’yans-Ekspert
- PAO Slavneft’-Megionneftegaz
- Issue: No 9 (2025)
- Pages: 3-15
- Section: Acoustic methods
- URL: https://journal-vniispk.ru/0130-3082/article/view/278955
- DOI: https://doi.org/10.31857/S0130308225090017
- ID: 278955
Cite item
Open Access
Access granted
Subscription Access
Abstract
For test sample that are modeled by shells of rotation — cylindrical, spherical and toroidal, arbitrarily located relative to the piezoelectric transducer, the parameters determined by the adhesive properties of the couplant (surface tension, contact angle of wetting) and dynamic viscosity are calculated: the thickness of the contact medium layer between transducer and input surface and the maximum thickness of the contact medium layer between transducer and input surface which acoustic contact is maintained, as well as their effect on the acoustic field. A comparison with experimental data is carried out.
About the authors
Alexandr Vladimirovich Michurov
OOO Al’yans-Ekspert
Author for correspondence.
Email: michurovav@yandex.ru
Russian Federation, 628684 Khanty-Mansi Autonomous Okrug—Ugra, Megion, Gubkina str., 35/1
Alexandr Victorovich Sokolkin
PAO Slavneft’-Megionneftegaz
Email: megio@yandex.ru
Russian Federation, 628680 Khanty-Mansi Autonomous Okrug—Ugra, Megion, Kuzmina str., 51
References
- Golubev A.S., Pavros S.K. Calculation of the acoustic path of an echo-flaw detector when monitoring products with a curved surface by the contact method // Izv. LETI. 1970. No. 89. P. 78—92.
- Ermolov I.N., Bychkov I.V., Rozina M.V. Restrictions in applying ARD-diagrams during tests of cylindrical articles // Defectoskopiya. 1993. No. 10. P. 3—12.
- Michurov A.V., Sokolkin A.V. A correction factor for the amplitude adjustment for the pulse echo ultrasonic inspection of components with curved surfaces // Defectoskopiya. 2016. No. 1. P. 18—29.
- Michurov A.V., Sokolkin A.V. Calculating the Influence of Refractions and Reflections from Curvilinear Surfaces of Shells of Revolution on Acoustic Field // Defectoskopiya. 2020. No. 1. P. 31—43.
- Michurov A.V., Sokolkin A.V. Calculating the energy transmission factor for a couplant layer with nonuniform thickness // Defectoskopiya. 2017. No. 8. P. 3—20.
- de Gennes P.-G. Capillarity and wetting phenomena: drops, bubbles, pearls, waves / de Gennes P.-G., Brochard-Wyart F., Quere D. Transl. by Reisinger A. New York: Springer, 2004. XV. 291 p.
- Zimon A.D. Adgeziya jidkosti i smachivanie (Liquid adhesion and wetting), Moscow: Himiya, 1974. 416 p.
- Kochin N.E., Kibel I.A., Roze N.V. Teoreticheskaya gidromehanika (Theoretical hydromechanics). V. II. Moscow: FIZMATGIZ, 1963. 728 p.
- Maier V.V. Kapli. Strui. Zvuk. Uchebnie issledovaniya (Drops. The jets. Sound. Educational research). Moscow: FIZMATLIT, 2008. 376 p.
- Michurov A.V., Sokolkin A.V. Povishenie dostovernosti ultrazvukovogo kontrolya svarnih soedinenii neftepromislovih truboprovodov (Improving the reliability of ultrasonic inspection of welded joints of oilfield pipelines), 76th International Youth Scientific Conference “Oil and Gas-2022”: conference proceedings / Compiled by: Maksimenko A.F., Komkov A.N., Fatkhutdinov R.R.; editor-in-chief Martynov V.G. Moscow: RGU nefti i gaza (NIU) imeni I.M. Gubkina, 2022. P. 330—337.
- Vargaftik N.B. Spravochnik po teplofizicheskim svoistvam gazov i jidkostei (Handbook of thermophysical properties of gases and liquids). Moscow: Nauka, 1972. 721 p.
- Sivtsov E.V., Gostev A.I., Krygina D.M., Yasnogorodskaya O.G. Surface properties of aqueous solutions of acrylic and n-vinylaminosuccinic acids (CO)polymers // Izv. SPbGTI (TU). 2019. No. 51 (77). P. 31—38.
- Lucenko A.A. Razrabotka modificirovannih vodno-akrilovih kompozitov s uluchshennimi zaschitno-dekorativnimi svoistvami (Development of modified water-acrylic composites with improved protective and decorative properties) / Doctoral Dissertation (PhD), Republic of Kazakhstan. Petropavlovsk: Manash Kozybayev North Kazakhstan university, 2022. 96 p.
- Semke A.V. (scientific director Semakina O.K.) Issledovanie kraevogo ugla smachivaniya poverhnosti filtruyuschego elementa (Investigation of the wetting edge angle of the filter element surface), conference proceedings of XVIII International Scientific Conference “Chemistry and Chemical Engineering in XXI Century” named after L.P. Kulev, May 29—June 1, 2017. Tomsk: TPU, 2017. P. 91—92.
- Arhipov V.A., Bondarchuk S.S., Usanina A.S., Shrager G.R. Influence of the Viscosity of a Liquid on the Dynamics of Spreading of its Drop // Journal of Engineering Physics and Thermophysics. 2015. V. 88. No. 1. P. 42—51.
- Rukovodstvo po bezopasnosti «Metodicheskie rekomendacii o poryadke provedeniya vizualnogo i izmeritelnogo kontrolya» (Methodological recommendations for procedure of visual and measuring testing method), Approved by Order No. 8 dated January 16, 2024. Of Federal Environmental, Industrial and Nuclear Supervision Service of Russia.
- Kalmykov V.V., Melnikov D.A., Gorbacheva M.S., Sukhareva A.A. Investigation of dependence of lubrication of construction materials from side of surface tension oil // Sovremennye naukoëmkie tehnologii. 2017. No. 6. P. 47—51.
- Krautkrämer J., Krautkrämer H. Werksoffprüfung mit Ultrashall, Berlin-Heidelberg-New York-London Paris-Tokyo: Springer-Verlag, 1986.
- Oil Graphing Tool [online resource]. URL: https://www.widman.biz/Calculadora/calculator.html.
