Impact Damage Influence Investigations on the Composite Skin-Stringer Joint Fatigue Characteristics Under Conditions of Vibroacoustic Loading

S. V. Dubinskii; Дубинский С. В.; F. S. Sevastyanov; Севастьянов Ф. С.; V. M. Kostenko; Костенко В. М.; S. L. Denisov; Денисов С. Л.

doi:10.31857/S0320791922600512

Impact Damage Influence Investigations on the Composite Skin-Stringer Joint Fatigue Characteristics Under Conditions of Vibroacoustic Loading

Authors: Dubinskii S.V.¹, Sevastyanov F.S.¹, Kostenko V.M.¹, Denisov S.L.¹
Affiliations:
1. Central Aerohydrodynamic Institute, 140181, Zhukovsky, Russia
Issue: Vol 69, No 2 (2023)
Pages: 261-269
Section: ФИЗИЧЕСКИЕ ОСНОВЫ ТЕХНИЧЕСКОЙ АКУСТИКИ
URL: https://journal-vniispk.ru/0320-7919/article/view/134433
DOI: https://doi.org/10.31857/S0320791922600512
EDN: https://elibrary.ru/ITFWCI
ID: 134433

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The article presents the results of studying the fatigue characteristics of skin–stringer joints (T‑samples) made of a polymer composite material subjected to random vibroacoustic loading with a wide spectrum. Experimental data were analyzed to determine the damage initiation and growth mechanisms, as well as the criterion and failure mode for samples with and without impact damages. The effect of impact damage on the fatigue characteristics of the test samples at different impact energies and vibroacoustic loading levels is demonstrated. The main patterns of the influence of defects on the fatigue characteristics are revealed, which can be used in the future in creating computational models for damage development in structures made of the polymer composite material under vibroacoustic loading.

Keywords

vibroacoustic loading, dynamic response, S-N curve, impact damage, polymer composite material (PCM)

References

Clarkson B.L. Review of Sonic Fatigue Technology // NASA Contractor Report 4587. 1994.
Нормы летной годности самолетов транспортной категории. Авиационные правила. Ч. 25 (АП-25).
Thomson A.G.R. Acoustic fatigue design data. AGARDograph 162. 1972.
ESDU Engineering Data: Acoustic Fatigue Series. V. 1. General, endurance under acoustic loading; V. 2. Loading actions, damping; V. 3. Stress/strain response of plate structures; V. 4. Natural frequencies of plate structures; V. 5. Natural frequencies of shell structures; V. 6. Natural frequencies of sandwich panels and box structures.
Панкратов А.И., Врачев А.В., Григорьев А.А., Макаревич В.И., Мозжерова Н.А., Николаев В.С. Руководство для конструкторов по проектированию самолетов. Т. 3. Прочность самолета. Книга 4. Усталостная прочность. Ресурс и надежность планера самолета. Выпуск 9. Методика испытания авиационных конструкций при акустическом нагружении. ЦАГИ. Инв. № 1292. 1981.
Xiao Y., White R.G., Aglietti G.S. An experimental characterization of the acoustic fatigue endurance of GLARE and comparison with that of CFRP // Composite Structures. 2005. V. 68. P. 455–470.
Xiao Y., White R.G., Aglietti G.S. Comparison of structural response and fatigue endurance of aircraft flap-like box structures subjected to acoustic loading // J. Acoust. Soc. Am. 2005. V. 117. № 5. P. 2820–2834.
Ajaj R.M., Allegri G., Isikveren A.T. Conceptual design and sizing of airframe panels according to safe-life acoustic fatigue criteria // Aeronautical J. 2011. V. 114. № 1162. P. 15–27.
Денисов С.Л., Медведский А.Л. Отклик ортотропных пластин на широкополосное акустическое воздействие при различных видах взаимной спектральной плотности действующей нагрузки // Механика композиционных материалов. 2012. Т. 18. № 4. С. 527–543.
ESDU 84027: Endurance of Fiber-Reinforced Composite, Laminated Structural Elements Subjected to Simulated Random Acoustic Loading. 16 (2014).
Di Spirito G. Acoustic Fatigue Analysis Of Composite Outboard And Inboard Flap Of A Commercial Aircraft. Ph.D Thesis, University of Naples Federico II. July 2015.
Uz C., Ata T.T. Acoustic fatigue and dynamic behavior of composite panels under acoustic excitation // Conf. Proc. Of The Society For Experimental Mechanics Series. Jan. 25–26, 2016. P. 219–229. Orlando, Florida.
Dubinskii S.V., Safonov A.A. Composite-Friendly Approach to Certification of Advanced Materials and Fabrication Methods Used in Aviation Industry // J. Machinery Manufacture and Reliability. 2017. V. 46. № 5. P. 501–506. https://doi.org/10.3103/s1052618817050041
Дубинский С.В., Севастьянов Ф.С., Голубев А.Ю., Денисов С.Л., Костенко В.М., Жаренов И.А. Расчетно-экспериментальное исследование влияния виброакустических нагрузок на прочность композитного соединения // Акуст. журн. 2019. Т. 65. № 4. С. 460–470.
Langley R.S. On the Forced Response of One-Dimensional Periodic Structures: Vibration Localization by Damping // J. Sound Vib. 1994. V. 178. P. 411–428.
Langley R.S. A Dynamic Stiffness Technique for the Vibration Analysis of Stiffened Shell Structures // J. Sound Vib. 1992. V. 156. P. 521–540.
Селихов А.Ф., Сеник В.Я., Хлебникова И.Г. Методика статистического анализа характеристик выносливости, прочности, живучести планера самолета. Руководство для конструкторов по проектированию самолетов. Т. III. Книга 4. Вып. 11. Издательский отдел ЦАГИ. 1979. 72 с.
