Properties of percolation channels in planar memristive structures base on epitaxial films of oxide perovskite compounds YBa 2 Cu 3 O 7 – δ  and La 1 –  x  Sr  x  MnO 3 – δ

A. N. Rossolenko; Россоленко А. Н.; N. A. Tulina; Тулина Н. А.; I. M. Shmytko; Шмытько И. М.; А. А. Ivanov; Иванов А. А.; A. V. Zotov; Зотов А. В.; I. Y. Borisenko; Борисенко И. Ю.; V. V. Sirotkin; Сироткин В. В.; V. A. Tulin; Тулин В. А.

doi:10.31857/S036767652270096X

Properties of percolation channels in planar memristive structures base on epitaxial films of oxide perovskite compounds YBa₂Cu₃O_7 – δ and La_1 – xSr_xMnO_3 – δ

Authors: Rossolenko A.N.¹, Tulina N.A.¹, Shmytko I.M.¹, Ivanov А.А.², Zotov A.V.³, Borisenko I.Y.³, Sirotkin V.V.³, Tulin V.A.³
Affiliations:
1. Osipyan Institute of Solid-State Physics of the Russian Academy of Sciences
2. National Research Nuclear University Moscow Engineering Physics Institute (MEPhI)
3. Institute of Microelectronics Technology and High Purity Materials of the Russian Academy of Sciences
Issue: Vol 87, No 4 (2023)
Pages: 541-545
Section: Articles
URL: https://journal-vniispk.ru/0367-6765/article/view/135359
DOI: https://doi.org/10.31857/S036767652270096X
EDN: https://elibrary.ru/NOXZNR
ID: 135359

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The choice of base materials and the use of their functional properties in the development of the structure and elucidation of the mechanism of resistive switching has been analyzed. Mesoscopic heterostructures based on epitaxial oriented 〈001〉 films of high-temperature superconductor YBa₂Cu₃O_{7 – δ} and doped manganite La_{1 –} _xSr_xMnO_{3 – δ}, were obtained, and the properties of percolation channels of structures based on these compounds were studied. The effects of “self-adapting electroforming” in microcontact heterostructures based on epitaxial films of manganite are observed. Numerical calculations using the critical electric field model have shown that “self-electroforming” occurs in strong electric fields and a gap structure is formed in the contact zone. This structure provides reproducibility of resistive switching.

References

Li Y., Wang Z., Midya R. et al. // J. Phys. D. 2018. V. 51. Art. No. 503002.
Wang C., Wu H., Gao B., Zhang et al. // Microelectron. Engin. 2018. V. 187–188. P. 121.
Perez-Tomas A. // Adv. Mater. Interfaces. 2019. V. 6. Art. No. 1970096.
Tulina N.A., Ivanov A.A. // J. Supercond. Nov. Magn. 2020. V. 33. P. 2279.
Тулина Н.А., Сироткин В.В., Борисенко И.Ю., Иванов А.А. // Изв. РАН. Сер. физ. 2013. Т. 77. № 3. С. 297; Tulina N.A., Sirotkin V.V., Borisenko I.Yu., Ivanov A.A. // Bull. Russ. Acad. Sci. Phys. 2013. V. 77. No. 3. P. 265.
Tulina N.A., Rossolenko A.N., Shmytko I.M. et al. // J. Supercond. Sci. Technol. 2019. V. 32. P. 5003.
Тулина Н.А., Россоленко А.Н., Шмытько И.М. и др. // Наноиндустрия. 2019. Т. 89. С. 237.
Tulina N.A., Borisenko I.Yu., Shmytko I.M. et al. // J. Supercond. Nov. Magn. 2020. V. 33. P. 3695.
Pickett W. E., Singh D.J., Krakauer H., Cohen R.E. // Science. 1992. V. 255. No. 5040. P. 46.
Dagotto E., Hotta N., Moreo A. // Phys. Reports. 2001. V. 344. P. 1.
Байков Ю.М., Никулин Е.И., Мелех Б.Т., Егоров В.М. // ФТТ. 2004. Т. 46. № 11. С. 2018.
Chaika A.N., Ionov A.M., Tulina N.A. et al. // J. Electron Spectrosc. Relat. Phenom. 2005. V. 148. P. 101.
Yanson I.K. // Low Temp. Phys. 1983. V. 6. P. 676.
Sano Y. // J. Appl. Phys. 1985. V. 58. P. 2651.
Jorgensen J. // Phys. Rev. B. 1990. V. 41. P. 1863.
Dagotto E. // Rev. Mod. Phys. 1994. V. 66. P. 763.
Hudgins J. // J. Electron. Mater. 2003. V. 33. P. 471.
