Email this article A comparison of the diagnostic capabilities of the ratio of acceleration time to total left ventricular ejection time (AT/ET) in determining the severity of aortic stenosis in patients with bicuspid and tricuspid aortic valve: retrospective comparative study
- Authors: Bazylev V.V.1, Babukov R.M.1, Bartosh F.L.1, Levina A.V.1, Mikulyаk A.I.1
-
Affiliations:
- Federal Centre for Cardiovascular Surgery
- Issue: Vol 13, No 4 (2022)
- Pages: 192-197
- Section: Original study articles
- URL: https://journal-vniispk.ru/2221-7185/article/view/134165
- DOI: https://doi.org/10.17816/CS108733
- ID: 134165
Cite item
Full Text
Abstract
Objective. We aimed to compare the diagnostic capabilities of the ratio of acceleration time to total left ventricular ejection time (AT/ET) in determining the severity of aortic stenosis (AS) in patients with bicuspid and tricuspid aortic valves (AV).
Material and methods. We retrospectively analyzed the data of 187 patients with moderate and severe AS who underwent diagnostic examination at the Penza Federal Center for Cardiovascular Surgery. The patients were divided into 2 groups based on whether their AV was tricuspid or bicuspid. Visual assessment of the AV structure was performed using transthoracic echocardiography (TTE). In indeterminate cases, computed tomography was used for the assessment.
Results. A comparative analysis of the echocardiographic characteristics of patients with tricuspid and bicuspid AV did not reveal a statistically significant difference between the patient groups (p ≤0.05). Linear regression analysis in patients with a tricuspid AV demonstrated a statistically significant correlation between AT/ET scores and peak gradient (Gmax) (r=0.68, р=0.03), mean gradient (Gmean) (r=0.78, р=0.01), effective orifice area (EOA) (r=0.7, р=0.03), and doppler velocity index (DVI) scores (r=0.72, р=0.02). In patients with a bicuspid AV, a similarly significant correlation was found between the AT/ET index and Gmax (r=0.67, р=0.02), Gmean (r=0.8, р <0.001), EOA (r=0.72, р=0.04), and DVI (r=0.75, р=0.01). The receiver operating characteristic analysis demonstrated a high predictive ability of AT/ET for severe aortic valve stenosis (with a value >0.35). The area under the curve in patients with tricuspid and bicuspid AV was 84 (p <0.001) and 86 (p <0.001), respectively. For determining severe AV stenosis in patients with a tricuspid AV, the sensitivity and specificity of AT/ET >0.35 was 84% and 75%, respectively; and in patients with a bicuspid AV, it was 87% and 78%, respectively.
Conclusion. The AT/ET ratio has comparable diagnostic capabilities in determining severe AS in patients with tricuspid and bicuspid AV structures. The AT/ET >0.35 is a highly sensitive parameter for defining severe AS for both morphologies of AV.
Keywords
Full Text
##article.viewOnOriginalSite##About the authors
Vladlen V. Bazylev
Federal Centre for Cardiovascular Surgery
Email: cardio-penza@yandex.ru
ORCID iD: 0000-0001-6089-9722
SPIN-code: 3153-8026
MD, D. Sci. (Med.), Prof.
Russian Federation, 6 Stasova Str., 440071, PenzaRuslan M. Babukov
Federal Centre for Cardiovascular Surgery
Author for correspondence.
Email: ruslan.babukov@mail.ru
ORCID iD: 0000-0002-7338-9462
SPIN-code: 2393-1170
cardiologist, ultrasound diagnosis doctor
Russian Federation, 6 Stasova Str., 440071, PenzaFedor L. Bartosh
Federal Centre for Cardiovascular Surgery
Email: cardio-penza@yandex.ru
ORCID iD: 0000-0001-5482-3211
SPIN-code: 1107-7579
MD, Cand. Sci. (Med.)
Russian Federation, 6 Stasova Str., 440071, PenzaAlena V. Levina
Federal Centre for Cardiovascular Surgery
Email: goralen1@mail.ru
ORCID iD: 0000-0002-3210-3974
ultrasound diagnosis doctor
Russian Federation, 6 Stasova Str., 440071, PenzaArtur I. Mikulyаk
Federal Centre for Cardiovascular Surgery
Email: cardio-penza@yandex.ru
ORCID iD: 0000-0002-9519-5036
SPIN-code: 3303-2522
MD, Cand. Sci. (Med.)
Russian Federation, 6 Stasova Str., 440071, PenzaReferences
- Barasch E, Fan D, Chukwu EO, et al. Severe isolated aortic stenosis with normal left ventricular systolic function and low transvalvular gradients: pathophysiologic and prognostic insights. J Heart Valve Dis. 2008;17(1):81–88.
- Minners J, Allgeier M, Gohlke-Baerwolf C, et al. Inconsistent grading of aortic valve stenosis by current guidelines: haemodynamic studies in patients with apparently normal left ventricular function. Heart. 2010;96(18):1463–1468. doi: 10.1136/hrt.2009.181982
- Belkin RN, Khalique O, Aronow WS, et al. Outcomes and survival with aortic valve replacement compared with medical therapy in patients with low-, moderate-, and severe-gradient severe aortic stenosis and normal left ventricular ejection fraction. Echocardiography. 2011;28(4):378–387. doi: 10.1111/j.1540-8175.2010.01372.x
- Clavel MA, Messika-Zeitoun D, Pibarot P, et al. The complex nature of discordant severe calcified aortic valve disease grading: new insights from combined Doppler echocardiographic and computed tomographic study. J Am Coll Cardiol. 2013;62(24):2329–2338. doi: 10.1016/j.jacc.2013.08.1621
- Zoghbi WA, Chambers JB, Dumesnil JG, et al. Recommendations for evaluation of prosthetic valves with echocardiography and doppler ultrasound: a report From the American Society of Echocardiography's Guidelines and Standards Committee and the Task Force on Prosthetic Valves, developed in conjunction with the American College of Cardiology Cardiovascular Imaging Committee, Cardiac Imaging Committee of the American Heart Association, the European Association of Echocardiography, a registered branch of the European Society of Cardiology, the Japanese Society of Echocardiography and the Canadian Society of Echocardiography, endorsed by the American College of Cardiology Foundation, American Heart Association, European Association of Echocardiography, a registered branch of the European Society of Cardiology, the Japanese Society of Echocardiography, and Canadian Society of Echocardiography. J Am Soc Echocardiogr. 2009;22(9):975–1014;quiz1082–1084. doi: 10.1016/j.echo.2009.07.013
- Ben Zekry S, Saad RM, Ozkan M, et al. Flow acceleration time and ratio of acceleration time to ejection time for prosthetic aortic valve function. JACC Cardiovasc Imaging. 2011;4(11):1161–1170. doi: 10.1016/j.jcmg.2011.08.012
- Gamaza-Chulián S, Camacho-Freire S, Toro-Cebada R, et al. Ratio of Acceleration Time to Ejection Time for Assessing Aortic Stenosis Severity. Echocardiography. 2015;32(12):1754–1761. doi: 10.1111/echo.12978
- Kamimura D, Hans S, Suzuki T, et al. Delayed Time to Peak Velocity Is Useful for Detecting Severe Aortic Stenosis. J Am Heart Assoc. 2016;5(10):e003907. doi: 10.1161/JAHA.116.003907
- Ringle Griguer A, Tribouilloy C, Truffier A, et al. Clinical Significance of Ejection Dynamics Parameters in Patients with Aortic Stenosis: An Outcome Study. J Am Soc Echocardiogr. 2018;31(5):551–560.e2.doi: 10.1016/j.echo.2017.11.015
- Gamaza-Chulián S, Díaz-Retamino E, Camacho-Freire S, et al. Acceleration Time and Ratio of Acceleration Time to Ejection Time in Aortic Stenosis: New Echocardiographic Diagnostic Parameters. J Am Soc Echocardiogr. 2017;30(10):947–955. doi: 10.1016/j.echo.2017.06.001
- Bazylev VV, Babukov RM, Bartosh FL, Gorshkova AV. Comparison of the hemodynamic parameters of transaortic blood flow in patients with aortic stenosis depending on the bicuspid or tricuspid valve structure. Medical Visualization. 2020;24(4):74–80. (In Russ).doi: 10.24835/1607-0763-2020-4-74-80
- Huntley GD, Thaden JJ, Alsidawi S, et al. Comparative study of bicuspid vs. tricuspid aortic valve stenosis. Eur Heart J Cardiovasc Imaging. 2018;19(1):3–8. doi: 10.1093/ehjci/jex211
- Richards KE, Deserranno D, Donal E, et al. Influence of structural geometry on the severity of bicuspid aortic stenosis. Am J Physiol Heart Circ Physiol. 2004;287(3):H1410–H1416. doi: 10.1152/ajpheart.00264.2003
- Baumgartner H Chair, Hung J Co-Chair, Bermejo J, et al. Recommendations on the echocardiographic assessment of aortic valve stenosis: a focused update from the European Association of Cardiovascular Imaging and the American Society of Echocardiography. Eur Heart J Cardiovasc Imaging. 2017;18(3):254–275. doi: 10.1093/ehjci/jew335
- McSweeney J, Dobson L, Macnab A. Acceleration time and ratio of acceleration time and ejection time in bicuspid aortic stenosis; a valid clinical measure? Heart. 2020;106(Suppl 2):A1–A118. doi: 10.1136/heartjnl-2020-BCS.8
