Vol 8, No 2 (2022)

Minerals and mineral assemblages

Tomamaeite Cu3Pt in native osmium from river sediments in the Nizhnie Sergi region, Central Urals

Sharygin V.V., Mikhailov I.G.

Abstract

The article is devoted to tomamaeite Cu3Pt from inclusions in a native osmium grain from alluvial river sediments in the Nizhnie Sergi region, Sverdlovsk oblast. It is the fourth finding of this mineral in the Urals. In addition to tomamaeite, native osmium Os0.36Ir0.33Ru0.31 contains the inclusions of digenite (or, possibly, roxbyite), millerite, Fe-Ni-Pt alloy, an unidentified Pd mineral, magnesiohornblendite, and lowCa pyroxene. In composition, tomamaeite is close to the ideal formula Cu3Pt and contains minor amounts of (wt. %) Pd (up to 2.0), Ir (up to 1.7), Ru and Ni (up to 0.6), and Fe (up to 0.2). In addition to native osmium, two grains of native ruthenium Ru0.54Os0.23Ir0.23 and Ru0.40Os0.31Ir0.29 are found in sediments. Our data suggest that the PGE minerals in river sediments could be sourced from mafic-ultramafic massifs located in the Nizhnie Sergi area. The formation of tomamaeite and coexisted minerals is related to the process of postmagmatic transformation of the primary PGE mineral assemblage, probably, during serpentinization of ultramafic rocks.

Mineralogy. 2022;8(2):5-14
pages 5-14 views

A sequence of formation of «uranpyrochlore» and fluorocalciopyrochlore in alkali pegmatites from the Vishnevye Mountains, South Urals

Popova V.I., Popov V.A., Blinov I.A., Kotlyarov V.A., Lebedeva S.M.

Abstract

The sequence of formation of pyrochlore crystals of various morphology and composition is considered in an aggregate with ilmenite and feldspar from nepheline-feldspar pegmatite at Mt. Dolgaya (Vishnevye Mountains, South Urals): altered yellowish green «uranium pyrochlore» with a UO3 content of 7.62–42.44 wt. % in different parts of the crystal, as well as fluorocalciopyrochlore, fersmite, and associated minerals. The alteration of «uranpyrochlore» includes fersmitization and silicification in contrast to relatively late fluorocalciopyrochlore and fersmite. The compositions and Raman spectra of altered «uranpyrochlore» and later fluorocalciopyrochlore are given.

Mineralogy. 2022;8(2):15-22
pages 15-22 views

New data on mineralogy of the Sugur copper deposit, South Urals

Popov V.A., Rassomakhin M.A., Popova V.I.

Abstract

The previous and new data on minerals and mineral assemblages of the Sugur copper deposit in the Sugur Mountains of South Urals are summarized. The ores of the deposit host abundant calcite, andradite, diopside, magnetite, chromite and serpentine together with pyrite, chalcopyrite, chalcocite, pyrrhotite, millerite, and rare baddeleyite. The genesis of the deposit was previously considered both contact-metasomatic and hydrothermal. The new data allow us to attribute the copper mineralization to a skarn-carbonatite system, which is locally recognized in the Karabash ultramafic massif.

Mineralogy. 2022;8(2):23-36
pages 23-36 views

Mineralogical-geochemical features of zircon from the Kumir granitic stock, Gorny Altai

Gusev A.I.

Abstract

Data on U-Pb age and composition of zircon from the Kumir granitic stock (Gorny Altai) and related greisens are presented for the first time. The magmatic, metamictic and pneumatolytic-hydrothermal zircons exhibit specific changes in main and trace elements with an increasing content of the high-field strength elemetns (U, Nb, Sc, REE) and decreasing Eu/Eu* and Ce/Ce* ratios. Depending on the composition and activity of volatiles in fluids and O fugacity, the REE contents and their ratios varied that is reflected on the tetrad effect of REE fractionation of М- and W- types.

Mineralogy. 2022;8(2):37-48
pages 37-48 views

Mineralogy and genesis of ultramafic rocks from the Kurtushiba ophiolite belt (Western Sayan)

Simonov V.A., Chernyshov A.I., Kotlyarov A.V.

Abstract

The studies of minerals and melt inclusions in ultramafic rocks of the Kurtushiba ophiolite belt (Western Sayan) allowed us to establish the conditions of mineral-forming processes during their formation. The features of the compositions of minerals of ultramafic rocks of the Idzhim, Kalny and Ergaki massifs are considered. The presence of melt inclusions directly indicates a magmatic origin of some Cr-spinels from dunites of the Idzhim massif. A close assemblage of Cr-spinels from chromitites with igneous Cr-spinels is important because of the possible formation of chromite ore from melts. The study of melt inclusions revealed the evolution of melts (picrites – picrobasalts – basalts – basaltic andesites) during the consecutive crystallization of minerals from the Western Sayan ophiolites. Computational modeling based on the compositions of melt inclusions and olivine indicates that olivine of ultramafic rocks of the Kurtushiba ophiolites crystallized at a decreasing pressure from 9.2 to 6.2 kbar and a decreasing temperature from 1550 to 1430 °С from picritic melts, which evolved to picrobasaltic melts. With a decrease in pressure to 3.8–2.3 kbar and temperature of picrobasaltic melts (1240–1230 °C), the formation of olivine terminated following by the crystallization of clinopyroxene from basaltic magmas at 2.7–1.9 kbar and about 1215 °C. The postmagmatic stage was characterized by plastic deformations of the Western Sayan ultramafic rocks at a decreasing temperature from 850 to 640 °C, which resulted in a successive change from protogranular to mesogranular structures and then to porphyroclastic and porphyroleist structures.

Mineralogy. 2022;8(2):49-63
pages 49-63 views

REE and Th minerals in the metasandstones of the Udokan basin (Russia)

Belogub E.V., Novoselov K.A., Shilovskikh V.V., Blinov I.A., Palenova E.E.

Abstract

Based on ICP-MS, optical and electron microscopy, and electron back-scatter diffraction data, the paper considers the distribution and the mode of occurrence of REEs and Th in metasandstones of the Lower Proterozoic Sakukan Formation, which host mineralization of the Udokan and Unkur copper sandstone deposits. The REE and Th contents increase in the layers enriched in iron oxides and minerals of natural heavy concentrate relatively to the background metasandstones. Detrital allanite is a major REE mineral, which occurs in layers enriched in iron oxides together with authigenic allanite, monazite, and unidentified Ca and REE carbonates. Thorium is concentrated in an authigenic silicate (thorite or thorogummite), which contains a significant amount of Fe, Ca, Al, and Cu and microinclusions of Cu and Pb sulfides and baryte. The diagenetic formation of authigenic REE and Th minerals is suggested as a result of desorption of these elements from siliceous-ferruginous gel-like sediments formed in river deltas and the wave-cut zone of the Proterozoic Sea.

Mineralogy. 2022;8(2):64-82
pages 64-82 views

Perovskite from spurrite-merwinite marbles of the Kochumdek contact aureole: application to U-Pb dating of a thermal event

Deviatiiarova A.S., Sokol E.V., Kokh S.N., Nigmatulina E.N.

Abstract

The paper presents the results of the first LA-ICP-MS U-Pb geochronological studies of 60 perovskite grains from spurrite marbles of the Kochumdek contact aureole (East Siberia). Perovskite is a dominant accessory mineral of U- and Th-poor marbles, which formed at the contact with traps of the Kuz’movsky complex (southwestern margin of the Tunguska Syneclise). The chemically homogeneous perovskite is characterized by limited substitutions: Ti4+ → Zr4+ (up to 2.5 mol. % CaZrO3) and Ca2+Ti4+ → REE3+Fe3+ (up to 1.8 mol. % REEFeO3). Perovskite is the main host for Th (up to 1550 ppm), U (up to 450 ppm), Ti, Zr, and LREEs (La + Ce + Pr + Nd); the element incorporation ratios are KTh = 516–870 and КU = 374. The U-Pb isotopic age of perovskite of 248.0 ± 7.2 Ma is in agreement with isotopic age values of traps of the Kuz’movsky complex.

Mineralogy. 2022;8(2):83-95
pages 83-95 views
