Simplified calculation of the actual fire resistance of steel structures with an epoxy thermally expanding flame retardant coating under the influence of a hydrocarbon temperature regime
- Authors: Golovanov V.I.1, Kryuchkov G.I.2, Pekhotikov A.V.1, Pavlov V.V.1
-
Affiliations:
- All-Russian Order of the Badge of Honor" Scientific Research Institute of Fire Protection of the Ministry of the Russian Federation for Civil Defense, Emergencies and Elimination of Consequences of Natural Disasters
- Academy of the State Fire Service of the Ministry of the Russian Federation for Civil Defense, Emergencies and Elimination of Consequences of Natural Disasters
- Issue: Vol 118, No 1 (2025)
- Section: Scientific and Technical Developments
- URL: https://journal-vniispk.ru/2411-3778/article/view/307449
- DOI: https://doi.org/10.37657/пб.v118i1.307449
- ID: 307449
Cite item
Full Text
Open Access
Access granted
Subscription Access
Abstract
A series of experimental studies to determine the fire protection efficiency of two-component epoxy thermally expanding coating for steel structures when exposed to hydrocarbon temperature regime has been carried out. The calculated thermo-physical characteristics of the flame retardant coating have been obtained. Based on calculation results there are constructed nomograms of heating of steel structures with the reduced thickness of metal from 2 to 20 mm and the thickness of epoxy coating from 1 to 9 mm. The obtained nomograms combined with the calculated value of the critical temperature allow to assess the fire resistance of steel structures of any configuration with different thicknesses of epoxy coating.
