Energy-saving modes for supply air preparation in comfort air conditioning systems

Cover Page

Cite item

Full Text

Abstract

In comfort air conditioning systems during preparation of the inlet outside air its humidification is necessary. The company “Venta” has developed and produces a compact apparatus for adiabatic humidification; its use in systems of ventilation and air conditioning leads to reduction of operational and capital expenditures.

About the authors

O. Ya. Kokorin

MGSU

Author for correspondence.
Email: info@eco-vector.com

Doctor of Engineering, Sciences, Prof.

Russian Federation

V. V. Komissarov

MGSU

Email: info@eco-vector.com

Doctor of Engineering, Sciences, Prof.

Russian Federation

A. V. Safronov

MGSU

Email: info@eco-vector.com

Doctor of Engineering, Sciences, Prof.

Russian Federation

References

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Rice. 1. Construction on the I-d-diagram of the year-round operation modes of the comfortable air conditioning system: H-HX - averaged values ​​of year-round changes in outdoor air parameters in the climate of Moscow. Warm season: H-Nnight - daily changes in outdoor air parameters; H-OH - cooling of the sanitary standard of the supply air in the air cooler of the central supply unit; OH -PN - heating in the fan and supply air ducts; ПН—В—У—absorption of heat and moisture emissions in the room by the cooled fresh air; ОХ.М—В is the absorption of excess heat by the internal air cooled in the DE; OH.M-PN-P - mixing in the DE of supply outdoor and cooled indoor air. P.UU—PN.K—heating in the first heating heater; PP.K—PN.Kh is adiabatic humidification; PP.Kh-PKh-V.Kh - mixing in the ejection closer; ПН.Х—У1 - absorption of heat and moisture in the serviced premises

Download (335KB)
Indexing metadata
3. Rice. Fig. 2. Daily changes in the thermal regime in an administrative building with a window to the south in the climate of Moscow during the warm period of the year: 1c - air temperature in the working area; 1n - outdoor air temperature; toxnH is the temperature of the cooled supply air; Ql+lC0M are constant sensible heat inputs from people and service equipment; Q is the heat of solar radiation penetrating into the room; Qm izb - total heat surplus in the room

Download (469KB)
Indexing metadata
4. Rice. Fig. 3. Scheme of the supply unit from the units of air conditioners STA manufactured by Venta1 - air valves interlocked with the magnetic starter MP of the fan unit; 2 - air filter; 3 - heat-releasing heat exchanger of the utilization plant; 4 - connecting pipelines to the heat-extracting heat exchanger in the exhaust unit; 5 - heater; 6 - hot water circulation pipelines through the heater; 7—automatic valve controlled by a sensor for monitoring the minimum value of the supply air temperature by a wet thermometer tnHMx; 8 - block of adiabatic humidification with an irrigated layer; 9 - water circulation pump; 10 - control sensor 1pnmkh connected by wires with automatic valve 7 and pump 9; 11 - air cooler; 12 - cold water circulation pipelines; 13 - automatic valve connected to the control sensor 14 t ; 15 - supply fan; 16 - supply air duct to the local DE in the premises

Download (325KB)
Indexing metadata
