Email this article The efficiency of thermal protection of ICE pistons with the micro-arc oxidation
- Authors: Dudareva N.Y.1, Kolomeichenko A.V.2, Kisel Y.E.3
-
Affiliations:
- Ufa University of Science and Technology
- Central Scientific Research Automobile and Automotive Engines Institute «NAMI»
- Bryansk State Engineering Technological University
- Issue: Vol 91, No 1 (2024)
- Pages: 101-112
- Section: Quality, reliability
- URL: https://journal-vniispk.ru/0321-4443/article/view/260275
- DOI: https://doi.org/10.17816/0321-4443-586629
- ID: 260275
Cite item
Abstract
BACKGROUND: In order to protect pistons of internal combustion engines (ICE) from burnout and increase their durability, it is reasonable to use ceramic coatings formed on the piston head with micro-arc oxidation (MAO). Many scientific papers have been devoted to the study of the efficiency of these coatings. However, most of these studies were carried out at laboratory facilities simulating the engine operation, generally, not taking into account the real thermophysical parameters of the MAO coating. Therefore, the thermal protection efficiency of these coatings is difficult to assess.
AIM: Study of efficiency of the thermal protection of pistons using a ceramic coating formed by micro-arc oxidation on the piston head with numerical simulation.
METHODS: The study was conducted in the SolidWorks Simulation software. Two piston aluminum alloys were used as the piston material: AK12d (with a silicon content of 12%) and AK4-1 (with a silicon content of 0.35%). Temperature loads corresponding to the operation of a real engine were applied to the surfaces of the model piston. At the first stage of the study, the thermal state of pistons made of different uncoated alloys was simulated. At the second and third stages of the study, the effect of the coating thickness on the piston thermal state was simulated. The piston material of the second study stage was the AK4-1 alloy. The piston material of the third study stage was the AK12d alloy. Ceramics, which properties correspond to the coatings properties formed with the micro-arc oxidation method on these alloys, were used as the coating material. The coating thickness varied in the range from 50 to 350 µm in increments of 100 µm. The probing method was used to determine the temperature in various areas of the piston, such as at the piston head surface at the MAO coating and under it, in the area of piston grooves, at a piston skirt and the piston head from the side of a crankcase.
RESULTS: With the simulation, it was found that:
- The micro-arc coating of the piston head reduces the thermal tension of the piston regardless of the aluminum alloy chemical composition.
- The efficiency of the piston’s thermal protection increases with an increase in the ceramic coating thickness and a decrease in its thermal conductivity coefficient.
- The greatest heat-protecting effect is achieved by the piston made of the AK12d eutectic alloy.
CONCLUSIONS: It is found that the MAO coating at the piston head is an effective way to reduce the thermal tension of the ICE pistons. Increasing the ceramic coating thickness and a decrease in its thermal conductivity coefficient increases the efficiency of the pistons thermal protection. Reducing the thermal conductivity of the MAO coating and increasing the MAO coating thickness increases the temperature on the coating surface.
Full Text
##article.viewOnOriginalSite##About the authors
Natalia Yu. Dudareva
Ufa University of Science and Technology
Author for correspondence.
Email: natalia_jd@mail.ru
ORCID iD: 0000-0003-2269-0498
SPIN-code: 6069-6928
Dr. Sci. (Engineering), Associate Professor, Professor of the of Internal Combustion Engines Department
Russian Federation, 32 Z. Validie street, 450076 UfaAlexander V. Kolomeichenko
Central Scientific Research Automobile and Automotive Engines Institute «NAMI»
Email: kolom_sasha@inbox.ru
ORCID iD: 0000-0002-3865-4486
SPIN-code: 2560-5163
Dr. Sci. (Engineering), Professor; Head of the Advanced Technologies Department of the Center for Agricultural Engineering
Russian Federation, MoscowYury E. Kisel
Bryansk State Engineering Technological University
Email: ypk2@mail.ru
ORCID iD: 0000-0002-5986-3922
SPIN-code: 9996-2193
Dr. Sci. (Engineering), Associate Professor; Professor of the General Technical Disciplines and Physics Department
Russian Federation, BryanskReferences
- Razuvaev AV, Slobodina EN. The operating conditions of the internal combustion engine with high temperature cooling. Journal of Physics Conference Series. 2020;1441(1):012026. doi: 10.1088/1742-6596/1441/1/012026
- Belov VP, Apelinskiy DV, Bezhenar VN. Experimental assessment of the temperature state of tractor diesel pistons. Tractors and Agricultural Machinery. 2022:89(2):111–120. doi: 10.17816/0321-4443-105717
- Caldera M, Massone JM, Martinez RA. Failure analysis of a damaged direct injection diesel engine piston. Journal of Failure Analysis and Prevention. 2017;17:979−988. doi: 10.1007/s11668-017-0327-y
- Li Z, Li J, Chen Z, et al. Experimental and computational study on thermomechanical fatigue life of aluminium alloy piston. Fatigue and Fracture of Engineering Materials and Structures. 2021;44:141−155. doi: 10.1111/ffe.13342
- Alshmri F. Lightweight material: Aluminium high silicon alloys in the automotive industry. Advanced Materials Research Vols. 2013;774-776:1271−1276. doi: 10.4028/
- Gots AN, Glinkin SA. Failure criteria of heat-stressed parts of piston engines and the review of methods for assessment of pistons durability. Tractors and agricultural machines. 2016;11:40−44. (In Russ). EDN: WYQMYL
- Sergeev S, Albieri MS, Yatsenko V, et al. Theoretical and practical study of possibility to decrease thermal stress in pistons of internal combustion diesel engine by using galvanic plasma modification. International Journal of Advanced Science and Technology. 2019;28(8):550−562. doi: 10.13140/RG.2.2.32284.44162
- Helmisyah AJ, Ghazali MJ, Abdullah S. Characterisation of thermal barrier coating on piston crown for compressed natural gas direct injection (CNGDI) engines. Applied Science and Engineering Progress. 2012;5(4):73−77. doi: 10.4028/
- Abhinav T, Kustagi HK, Shankar AR. Adhesion Strength of Plasma Sprayed Coatings — A Review. Intelligent Manufacturing and Energy Sustainability. Smart Innovation, Systems and Technologies. 2020;169:77−83. doi: 10.1007/978-981-15-1616-0_8
- Markov MA, Bykova AD, Krasikov AV, et al. Formation of wear- and corrosion-resistant coatings by the microarc oxidation of aluminum. Refractories and Industrial Ceramics. 2018;4(59):207–214. doi: 10.1007/s11148-018-0207-3
- Suminov IV, Epelfeld AV, Lyudin VB, et al. Microarc oxidation: theory, technology, equipment. Moscow: ECOMET; 2005. (In Russ).
- Kolomeichenko AV, Kravchenko IN. Elemental composition and microhardness of the coatings prepared on faced aluminum alloys by plasma electrolytic oxidation in a silicate-alkaline electrolyte. Russian Metallurgy (Metally). 2019;(13):1410−1413. doi: 10.1134/S0036029519130147
- Basinyuk VL, Kolomeichenko AV, Mardosevich EI, et al. Thermal state of friction contact of aluminum — alloy parts coated with Al2O3. Journal of Friction and Wear. 2005;26(3):62−70.
- Curran JA, Kalkancı H, Magurova Yu. Mullite-rich plasma electrolytic oxide coatings for thermal barrier applications. Surface and Coatings Technology. 2007;201:8683−8687. doi: 10.1016/j.surfcoat.2006.06.050
- Dudareva NYu, Kruglov AB, Gallyamova RF. Structure and thermophysical properties of coatings formed by the method of microarc oxidation on an aluminum alloy AK4-1. Solid State Phenomena. 2018;284:1235−1241. doi: 10.4028/
- Dudareva NYu, Ivashin PV, Kruglov AB. Investigation of the thermophysical properties of the oxide layer formed by microarc oxidation on Al-Si alloy. MATEC Web of Conferences. 2017;129:02015. doi: 10.1051/matecconf/201712902015
- Mar’in DM, Khokhlov AL, Shlushchenko AA, et al. Influence of oxidized layer on thermal stress of internal combustion engine pistons. Science and world. 2014;1(5):108−109. (In Russ).
- Subaeva AK, Khokhlov AL. The thermal factor reduction of the piston in the internal combustion engine by the method of micro-arc oxidation of the head. The Turkish Online Journal of Design, Art and Communication TOJDAG. 2017:1749–1756. doi: 10.7456/1070DSE/155
- Shpakovsky VV. Influence of partially dynamic thermal insulation on the temperature state of the piston surface. Internal combustion engines. 2010;2:92–95. (in Russ). EDN: TTYTPX
- Shackelford JF, Doremus RH. Ceramic and Glass Materials. Structure, Properties and Processing. New York : Springer; 2008. doi: 10.1007/978-0-387-73362-3
- Nudehi S, Steffen JR. Analysis of Machine Elements Using SolidWorks Simulation 2016. Mission, KS: SDC Publications; 2016.
- MTI. An Introduction to Stress Analysis Applications with SolidWorks Simulation, Student Guide Massachusetts. USA: Massachusetts; 2010.
- Gorbachev VG, Zagayko SA, Rudaya NV, et al. Simulation system “Albea” (core). User Manual. Ufa : UGATU, 1995. (In Russ).
- Musin N, Dudareva N. Investigation of the effect of the coating formed by microarc oxidation on the piston top on the thermal state of the internal combustion engine parts. MATEC Web of Conferences. 2018;224:03008. doi: 10.1051/matecconf/201822403008.
- Zakharov VV. The effect of additional annealing before quenching on the properties of clad sheets made of AK4-1h alloy manufactured according to the technology of LLC “KUMZ”. Technology of light alloys. 2023;1:6–11. (In Russ). doi: 10.24412/0321-4664-2023-1-6-11
- Mechalikh M, Benhammou A, Zidane I, et al. Study of piston thermo-elastic behaviour under thermomechanical solicitations. International Journal of Automotive and Mechanical Engineering. 2019;16(4):7287–7298
- Liu Y, Lei J, Niu X, et al. Experimental and simulation study on aluminium alloy piston based on thermal barrier coating. Scientific Reports. 2022;12:10991. doi: 10.1038/s41598-022-15031-x
- Beletsky VM, Krivov GA. Aluminum alloys (composition, properties, technology, application). Guide. Kiev: Komintech; 2005. (In Russ).
- Alyamovsky AA. Engineering calculations in SolidWorks Simulation. Moscow: DMK-Press; 2010. (in Russ).
