The dynamic stability of physically nonlinear plate systems under biaxial compression
- Authors: Ivanov S.P.1,2, Ivanov O.G.1,2, Ivanova A.S.1
-
Affiliations:
- Volga State University of Technology
- Mari State University
- Issue: Vol 14, No 2 (2018)
- Pages: 132-141
- Section: Buckling analysis
- URL: https://journal-vniispk.ru/1815-5235/article/view/346310
- DOI: https://doi.org/10.22363/1815-5235-2018-14-2-132-141
- ID: 346310
Cite item
Full Text
Abstract
The article presents the method of dynamic stability analysis of plate systems with nonshifting ribs. A plate system under the biaxial dynamic compression loads is considered. The Kirchhoff - Love hypotheses, the nonlinear-elastic body hypothesis are considered the basis of the calculations. The material of the plate system is assumed to be physically nonlinear, stress-deformation diagram is approximated in the form of a cubic polynomial. The displacement of points in normal direction to middle plane of plates is presented in the form of Vlasov expansion. To derive the basic differential equations of stability, the strainenergy method and Vlasov's variation method are used. The extreme value of total energy of the system is defined using Euler - Lagrange equation, after solving of which the set of basic nonlinear differential equations of buckling of the plate system with non-shifting ribs under dynamic compression loads is given. As an example, the stability calculation of physically nonlinear T-shaped plate system hinge-supported along the contour is carried out. Buckling of the plate system occurs longitudinally on one half-wave of sinusoid. At the solution of a task in the first approximation, a nonlinear differential equation is derived, the numerical integration of which was carried out by the Runge - Kutta method. Based on the results of the calculations, graphs of the relative magnitude of deflection against the dynamic coefficient are plotted. The influence of the degree of physical nonlinearity of the material, the rate of change of the dynamic compressive load on the dynamic criterion of buckling of the plate system was studied.
About the authors
Sergey Pavlovich Ivanov
Volga State University of Technology; Mari State University
Author for correspondence.
Email: sp-ivanov@mail.ru
Doctor of Science, Professor, Head of Department of Strength of Materials and Applied Mechanics, the Volga State University of Technology; Professor of Department of Electro-Mechanics, the Mari State University. He is the author of 147 scientific articles, 2 monographs, 4 textbooks, 20 names of educational literature. General research interests: strength, stability and vibrations analyses of the physically and geometric nonlinear rods, plates and plate systems
3 Lenin Sq., Yoshkar-Ola, 424000, Russian Federation; 1 Lenin Sq., Yoshkar-Ola, 424000, Russian FederationOleg Gennadevich Ivanov
Volga State University of Technology; Mari State University
Email: IvanovOG@volgatech.net
Cand. Sc, Assistant Professor, Associate Professor of the Department of Strength of Materials and Applied Mechanics, the Volga State University of Technology. He is the author of 35 scientific articles, 1 monograph, 6 names of educational literature. General research interests: strength and stability analyses of the physically nonlinear plates and plate systems resting on elastic foundation
3 Lenin Sq., Yoshkar-Ola, 424000, Russian Federation; 1 Lenin Sq., Yoshkar-Ola, 424000, Russian FederationAnastasia Sergeevna Ivanova
Volga State University of Technology
Email: ivanova-a-s@list.ru
Aspirant, Senior Lecturer of the Department of Strength of Materials and Applied Mechanics, the Volga State University of Technology. At the present time she works on the Candidate's dissertation «The dynamic stability of physically nonlinear rods, plates and plate systems» in the specialty 05.23.17 - Structural Mechanics. She is the author of 15 scientific articles, 1 name of educational literature. General research interests: stability analyses of the physically nonlinear rods, plates and plate systems
3 Lenin Sq., Yoshkar-Ola, 424000, Russian FederationReferences
- Volmir, A.S. (1967). Stability of deformable systems, Moscow: Science, 984 p. (In Russ.)
- Trushin, S.I., Zhuravleva, T.A., Sysoeva, E.V. (2016). Dynamic buckling of nonlinearly deformable reticulate plates from composite material with different lattice configurations, Nauchnoe Obozrenie, No 4, p. 44–51. (In Russ.)
- Vescovini, R., Dozio, L. (2015). Exact refined buckling solutions for laminated plates under uniaxial and biaxial loads, Composite Structures, Vol. 127, p. 356–368.
- Nazarimofrad, E., Barkhordar, A. (2016). Buckling analysis of orthotropic rectangular plate resting on Pasternak elastic foundation under biaxial in-plane loading, Mechanics of Advanced Materials and Structures, Vol. 23, No 10, p. 1144–1148.
- Khamitov, T.K., Fatykhova, R.R. (2016). On stability of elastic-plastic cylindrical shell under longitudinal impact, News of the Kazan State University of Architecture and Engineering, No 4 (38), p. 490–496. (In Russ.)
- Cao, G., Chen, Z., Yang, L., Fan, H., Zhou, F. (2015). Analytical study on the buckling of cylindrical shells with arbitrary thickness imperfections under axial compression, Journal of Pressure Vessel Technology Transactions of the ASME, Vol. 137, No 1.
- Trushin, S.I., Zhuravleva, T.A., Sysoeva, E.V. (2013). The stability of nonlinear deformable cylindrical composite shells under non-uniform loads, Structural Mechanics of Engineering Constructions and Buildings, № 2, p. 3–10. (In Russ.)
- Ivanov, S.P., Ivanova, A.S. (2015). Prilozheniye variacionnogo metoda V.Z. Vlasova k resheniyu nelinejnykh zadach plastinchatykh system: Monographiya, Yoshkar-Ola: PGTU, 248 p. (In Russ.)
- Lukash, P.A. (1978). Osnovy nelinejnoj stroitel’noj mekhaniki, Moscow: Strojizdat, 204 p. (In Russ.)
- Vlasov, V.Z. (1958). Tonkostennye prostranstvennye sistemy, Moscow: Gosstrojizdat, 502 p. (In Russ.)
- Ivanov, S.P., Ivanova, A.S. (2015). The static stability of plates and plate systems with nonshifting ribs under biaxial compression, Structural Mechanics of Engineering Constructions and Buildings, No 4, p. 63–67. (In Russ.)
