Investigation of the structural-phase state and mechanical properties of ZrCrN coatings obtained by plasma-assisted vacuum arc evaporation

A. V. Filippov; Филиппов А. В.; N. N. Shamarin; Шамарин Н. Н.; E. N. Moskvichev; Москвичев Е. Н.; O. S. Novitskaya; Новицкая О. С.; E. O. Knyazhev; Княжев Е. О.; Y. A. Denisova; Денисова Ю. А.; A. A. Leonov; Леонов А. А.; V. V. Denisov; Денисов В. В.

doi:10.17212/1994-6309-2022-24.1-87-102

Investigation of the structural-phase state and mechanical properties of ZrCrN coatings obtained by plasma-assisted vacuum arc evaporation

Authors: Filippov A.V.¹, Shamarin N.N.¹, Moskvichev E.N.¹, Novitskaya O.S.¹, Knyazhev E.O.¹, Denisova Y.A.¹, Leonov A.A.¹, Denisov V.V.¹
Affiliations:
Issue: Vol 24, No 1 (2022)
Pages: 87-102
Section: MATERIAL SCIENCE
URL: https://journal-vniispk.ru/1994-6309/article/view/301772
DOI: https://doi.org/10.17212/1994-6309-2022-24.1-87-102
ID: 301772

Cite item

Full Text

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

Introduction. Modern technologies allow the synthesis of nanostructured coatings from multiple chemical elements to combine different physical, mechanical, and chemical properties in one coating. Promising in this respect are coatings formed via layer-by-layer deposition of zirconium and chromium nitrides. The deposition of various chemical elements on various substrates requires separate studies in order to produce high-strength and wear-resistant coatings. The purpose of this work is to study the structural-phase state and mechanical properties of ZrCrN coatings formed by plasma-assisted vacuum arc evaporation. Materials and methods. The investigation is performed on specimens comprising VK8 hard alloy substrates with zirconium and chromium nitride coatings as well as with multilayer ZrCrN coatings. The methods used are confocal laser scanning microscopy, X-ray diffraction analysis, high-resolution scanning electron microscopy, nanoindentation, and scratching. Results and discussion. The experimental results obtained showed that the mode of multilayer ZrCrN coating evaporation greatly affects the structure, morphology, surface roughness, and mechanical properties of the coatings. In particular, by varying the substrate rotation speed during coating deposition it is possible to control the deposition time of each coating layer and thereby modify the layer properties. Conclusions. The investigation results showed that variation of the evaporation conditions allows one to obtain a ZrCrN coating with a high nanohardness of 45 GPa on a VK8 alloy substrate. Analysis of mechanical test results indicate good adhesion between the studied coatings and the substrate. Scratch tests revealed that fracture of CrN and ZrN coatings occurs by the cohesive mechanism, and the surface of ZrCrN coatings exhibits uniform scratches without any signs of fracture. Based on the results obtained, ZrCrN-2…ZrCrN-4 coatings can be recommended for use as hard and wear-resistant coatings.

Keywords

Coating, morphology, nitrides, structure, phase composition

References

Tribology of multilayer coatings for wear reduction: a review / M. Khadem, O.V. Penkov, H.K. Yang, D.E. Kim // Friction. – 2017. – Vol. 5 (3). – P. 248–262. – doi: 10.1007/s40544-017-0181-7.
Krella A. Resistance of PVD coatings to erosive and wear processes: a review // Coatings. – 2020. – Vol. 10 (10). – P. 921. – doi: 10.3390/COATINGS10100921.
Каменева А.Л., Сушенцов Н.И., Клочков А. Зависимость морфологии, свойств, теплового и напряженного состояния пленок от технологических параметров магнетронного распыления // Технология металлов. – 2010. – № 11. – С. 38–42.
Effect of thermal annealing in vacuum and in air on nanograin sizes in hard and superhard coatings Zr-Ti-Si-N / A.D. Pogrebnjak, A.P. Shpak, V.M. Beresnev, D.A. Kolesnikov, Yu.A. Kunitskii, O.V. Sobol, V.V. Uglov, F.F. Komarov, A.P. Shypylenko, N.A. Makhmudov, A.A. Demyanenko, V.S. Baidak, V.V. Grudnitskii // Journal of Nanoscience and Nanotechnology. – 2012. – Vol. 12, N 12. – P. 9213–9219. – doi: 10.1166/jnn.2012.6777.
Nanoindentation induced plastic deformation in nanocrystalline ZrN coating / Z.T. Wu, Z.B. Qi, D.F. Zhang, Z.C. Wang // Materials Letters. – 2016. – Vol. 164. – P. 120–123. – doi: 10.1016/j.matlet.2015.10.091.
Characterization of zirconium nitride coatings deposited by cathodic arc sputtering / K.A. Gruss, T. Zheleva, R.F. Davis, T.R. Watkins // Surface and Coatings Technology. – 1998. – Vol. 107, iss. 2–3. – P. 115–124. – doi: 10.1016/S0257-8972(98)00584-2.
Atar E., Çimenoglu H., Kayali E.S. Effect of oxidation on the wear behavior of a ZrN coating // Key Engineering Materials. – 2005. – Vol. 280. – P. 1459–1462. – doi: 10.4028/ href='www.scientific.net/kem.280-283.1459' target='_blank'>www.scientific.net/kem.280-283.1459.
Flexible hydrophobic ZrN nitride films / J. Musil, S. Zenkin, Š. Kos, R. Cerstvý, S. Haviar // Vacuum. – 2016. – Vol. 131. – P. 34–38. – doi: 10.1016/j.vacuum.2016.05.020.
Mo J.L., Zhu M.H. Tribological characterization of chromium nitride coating deposited by filtered cathodic vacuum arc // Applied Surface Science. – 2009. – Vol. 255, iss. 17. – P. 7627–7634. – doi: 10.1016/j.apsusc.2009.04.040.
Evaluation of adhesive behaviors of chromium nitride coating films produced by arc ion plating method / R.I. Murakami, Y.H. Kim, K. Kimura, D. Yonekura, D.H. Shin // JSME International Journal Series A, Solid Mechanics and Material Engineering. – 2006. – Vol. 49, iss. 1. – P. 123–129. – doi: 10.1299/jsmea.49.123.
Effect of chromium nitride coating on the corrosion and wear resistance of stainless steel / J. Jagielski, A.S. Khanna, J. Kucinski, D.S. Mishra, P. Racolta, P. Sioshansi, E. Tobin, J. Thereska, V. Uglov, T. Vilaithong, J. Viviente, S.-Z. Yang, A. Zalar // Applied Surface Science. – 2000. – Vol. 156, iss. 1–4. – P. 47–64. – doi: 10.1016/S0169-4332(99)00350-5.
Corrosion prevention of chromium nitride coating with an application to bipolar plate materials / J. Park, P. Kusumah, Y. Kim, K. Kim, K. Kwon, C.K. Lee // Electrochemistry. – 2014. – Vol. 8, iss. 8. – P. 658–662. – doi: 10.5796/electrochemistry.82.658.
Multilayered chromium/ chromium nitride coatings for use in pressure die-casting / A. Lousa, J. Romero, E. Martínez, J. Esteve, F. Montalà, L. Carreras // Surface and Coatings Technology. – 2001. – Vol. 146. – P. 268–273. – doi: 10.1016/S0257-8972(01)01476-1.
Control of microstructures and properties of dc magnetron sputtering deposited chromium nitride films / Z.G. Zhang, O. Rapaud, N. Bonasso, D. Mercs, C. Dong, C. Coddet // Vacuum. – 2008. – Vol. 82, iss. 5. – P. 501–509. – doi: 10.1016/j.vacuum.2007.08.009.
Thermal stability and corrosion resistance of Cr/CrN multilayer coatings on Ti6Al4V alloy / P. Wiecinski, J. Smolik, H. Garbacz, K.J. Kurzydlowski // Solid State Phenomena. – 2015. – Vol. 237. – P. 47–53. – doi: 10.4028/ href='www.scientific.net/SSP.237.47' target='_blank'>www.scientific.net/SSP.237.47.
Microstructure of thick chromium-nitride coating synthesized using plasma assisted MOCVD technique / A. Dasgupta, A. Premkumar, F. Lawrence, L. Houben, P. Kuppusami, M. Luysberg, K.S. Nagaraja, V.S. Raghunathan // Surface and Coatings Technology. – 2006. – Vol. 201, iss. 3–4. – P. 1401–1408. – doi: 10.1016/j.surfcoat.2006.02.005.
Shapovalov Y.A., Lee D.B. High temperature oxidation of TiAl (La) N coating deposited on a steel substrate by arc-ion plating // Materials Science Forum. – 2006. – Vol. 510. – P. 410–413.
Milošev I., Strehblow H.H., Navinšek B. Comparison of TiN, ZrN and CrN hard nitride coatings: electrochemical and thermal oxidation // Thin Solid Films. – 1997. – Vol. 303, iss. 1–2. – P. 246–254. – doi: 10.1016/S0040-6090(97)00069-2.
Maksakova O.V., Pogrebnjak O.D., Beresnev V.M. Features of investigations of multilayer nitride coatings based on Cr and Zr // Успехи физики металлов. – 2018. – Т. 19, № 1. – C. 25–48. – doi: 10.15407/ufm.19.01.025.
Microstructures and tribological properties of CrN/ZrN nanoscale multilayer coatings / Z.G. Zhang, O. Rapaud, N. Allain, D. Mercs, M. Baraket, C. Dong, C. Coddet // Applied Surface Science. – 2009. – Vol. 255, iss. 7. – P. 4020–4026. – doi: 10.1016/j.apsusc.2008.10.075.
Fracture resistant and wear corrosion performance of CrN/ZrN bilayers deposited onto AISI 420 stainless steel / N.A. de Sánchez, H.E. Jaramillo Suárez, Z. Vivas, W. Aperador, C. Amaya, J.C. Caicedo // Advanced Materials Research. – 2008. – Vol. 38. – P. 63–75. – doi: 10.4028/ href='www.scientific.net/amr.38.63' target='_blank'>www.scientific.net/amr.38.63.
Kim M.K., Kim G.S., Lee S.Y. Synthesis and characterization of multilayer CrN/ZrN coatings // Metals and Materials International. – 2008. – Vol. 14, N 4. – P. 465–470. – doi: 10.3365/met.mat.2008.08.465.
Enhancing mechanical and tribological performance of multilayered CrN/ZrN coatings / J.J. Zhang, M.X. Wang, J. Yang, Q.X. Liu, D.J. Li // Surface and Coatings Technology. – 2007. – Vol. 201, iss. 9–11. – P. 5186–5189. – doi: 10.1016/j.surfcoat.2006.07.093.
Structural and mechanical properties of multilayered gradient CrN/ZrN coatings / D.J. Li, F. Liu, M.X. Wang, J.J. Zhang, Q.X. Liu // Thin Solid Films. – 2006. – Vol. 506. – P. 202–206. – doi: 10.1016/j.tsf.2005.08.031.
Magnetron sputtering deposition of polycrystalline CrN/ZrN superlattice coatings / M.X. Wang, J.J. Zhang, Q.X. Liu, D.J. Li // Surface Review and Letters. – 2006. – Vol. 13, N 2–3. – P. 173–177. – doi: 10.1142/s0218625x06008177.
Возможности структурной инженерии в многослойных вакуумно-дуговых ZrN/CrN-покрытиях путем изменения толщины нанослоев и подачи потенциала смещения / О.В. Соболь, А.А. Андреев, В.Ф. Горбань, В.А. Столбовой, А.А. Мейлехов, А.А. Постельник // Журнал технической физики. – 2016. – Т. 86, № 7. – С. 100–103.
Influence of pressure of working atmosphere on the formation of phase-structural state and physical and mechanical properties of vacuum-arc multilayer coatings ZrN/CrN / O.V. Sobol’;, A.A. Andreev, V.F. Gorban’;, V.A. Stolbovoy, A.A. Meylekhov, A.A. Postelnyk, A.V. Dolomanov // Вопросы атомной науки и техники. – 2016. – № 1 (101). – С. 134–139.
Structural engineering of the vacuum Arc ZrN/CrN multilayer coatings / O.V. Sobol’;, A.A. Andreev, V.F. Gorban’;, A.A. Meylekhov, A.A. Postelnyk, V.A. Stolbovoy // Journal of Nano- and Electronic Physics. – 2016. – Vol. 8, N 1. – P. 01042-1.
The effect of Cr/Zr chemical composition ratios on the mechanical properties of CrN/ZrN multilayered coatings deposited by cathodic arc deposition system / S.F. Chen, Y.C. Kuo, C.J. Wang, S.H. Huang, J.W. Lee, Y.C. Chan, J.G. Duh, T.E. Hsieh // Surface and Coatings Technology. – 2013. – Vol. 231. – P. 247–252. – doi: 10.1016/j.surfcoat.2012.03.002.
Mechanical and tribological properties evaluation of cathodic arc deposited CrN/ZrN multilayer coatings / S.H. Huang, S.F. Chen, Y.C. Kuo, C.J. Wang, J.W. Lee, Y.C. Chan, H.W. Chen, J.G. Duh, T.E. Hsieh // Surface and Coatings Technology. – 2011. – Vol. 206, iss. 7. – P. 1744–1752. – doi: 10.1016/j.surfcoat.2011.10.029.
Nanoscale architecture of ZrN/CrN coatings: microstructure, composition, mechanical properties and electrochemical behavior / P.M. Samim, A. Fattah-alhosseini, H. Elmkhah, O. Imantalab // Journal of Materials Research and Technology. – 2021. – Vol. 15. – P. 542–560. – doi: 10.1016/j.jmrt.2021.08.018.
Effect of heat input on phase content, crystalline lattice parameter, and residual strain in wire-feed electron beam additive manufactured 304 stainless steel / S.Yu. Tarasov, A.V. Filippov, N.L. Savchenko, S.V. Fortuna, V.E. Rubtsov, E.A. Kolubaev, S.G. Psakhie // International Journal of Advanced Manufacturing Technology. – 2018. – Vol. 99. – P. 2353–2363. – doi: 10.1007/s00170-018-2643-0.
