电邮这篇文章 Development of the Ge-MDST instrument structure with an induced p-type channel
- 作者: Alyabina N.A.1, Arkhipova E.A.2, Buzynin Y.N.1,2, Denisov S.A.1, Zdoroveishchev A.V.1, Titova A.M.1, Chalkov V.Y.1, Shengurov V.G.1
-
隶属关系:
- Nizhegorodsky State University named after N.I. Lobachevsky
- Institute of Microstructure Physics of the Russian Academy of Sciences
- 期: 卷 53, 编号 3 (2024)
- 页面: 259-264
- 栏目: ПРИБОРЫ
- URL: https://journal-vniispk.ru/0544-1269/article/view/267570
- DOI: https://doi.org/10.31857/S0544126924030077
- ID: 267570
如何引用文章
开放存取
##reader.subscriptionAccessGranted##
订阅存取
详细
The conditions for the growth of n-type Ge conduction layers by the HW CVD method with the parameters required to create a Ge-TIR transistor with an induced p-type channel are determined. The conditions of deposition by electron beam deposition and subsequent annealing of layers of a high-k dielectric ZrO2:Y2O3 are optimized, allowing to achieve a leakage current of 5 × 10–6 A/cm2. For the developed instrument structure, some parameters of the Ge-TIR transistor were calculated, such as the channel length, the maximum voltage between the drain and the source, and the breakdown voltage.
